Product Update | New Probe HFD-0191 For the Narda FieldMan
The New HFD-0191 Probe is Now Available for the Narda FieldMan
Introducing the HFD-0191 probe for isotropic measurements of magnetic fields. Supporting measurements ranging from 27 MHz to 1 GHz, the HFD-0191 probe is compatible with the Narda FieldMan EMF Meter and features a digital interface that improves sensitivity and dynamic range. The Narda HFD-0191 probe is suitable for use in all major areas of electromagnetic field exposure in:
Radio and TV broadcasting
Telecommunications
High frequency industrial applications
With the probe digitally transmitting measurement data to the base unit, the FieldMan does not need to be calibrated and will not impact the measurement results. Instead, the probe can be calibrated at several frequencies, and a correction factor can be applied if the predominating field strength is known, further increasing measurement accuracy.
The new HFD-0191 probe features:
Isotropic (non-directional) measurement
High dynamic range of 60 dB
Wide True RMS range up to 1 A/m
Digital probe interface
Probe interface self-testing with an integrated sensor function test
Automatic offset correction with no zero adjustment required
Wide temperature range from -20 °C to +50 °C
High immunity at 50/60 Hz
Factory calibration up to 1 GHz
For a comparison of the probes available for the Narda FieldMan, refer to the table on page 19 of the Narda FieldMan brochure below.
Narda Safety Test Solutions is a leading company in the design and manufacture of electromagnetic field measurement instruments including high frequency monitors, low frequency monitors, area radiation meters and personal radiation meters. Narda radiation monitoring equipment is available in Australia exclusively from Air-Met Scientific for sale, service and rental. Contact your local Air-Met Scientific for more information on the Narda range.
